PORTABLE REVERSE OSMOSIS WATER PURIFIER​

FOR DIALYIS

​

DG series

Single or Double Pass RO

ANVISA registered product 80839350001

gmp certified company.jpg
made in brazil.jpg
anvisa registered product.jpg
registro-anvisa-osmose-reversa-IPABRAS_e

Best seller portable reverse osmosis water purifier for dialysis, manufactured in GMP certificated factory, ANVISA registered product. Robust machine with stainless steel cabinet and built-in pretreatment. Easy to use and operate, with best preventive protection against lack of water and user friendly disinfection system. Single or double pass RO versions available.

osmose-reversa-portatil-IPABRAS-a-melhor

Best preventive protection against lack of water.

User-friendly disinfection system with quick connect fittings.

MAIN USE:

  • Water for acute dialysis

  • ICU and homecare

INTELLIGENT CONTROL

  • Easy operation by pressing one button.

  • Automatic start-stop feature to fill tanks.

  • Microprocessed automatic control.

  • Conductivity meter with alarm and adjustable setpoint.

  • Total hour meter for user to control lifetime.

  • Lack of water preventive protection with alarm.



USER FRIENDLY DISINFECTION SYSTEM

  • Disinfection kit with reusable bottle and quick connect fittings.

  • This disinfection method works with closed circuit and does not require any additional space for maintenance, which permits the user to run it anywhere the machine is, without the need to transport it for maintenance.



WATER SAVING

  • Concentrate and oversupply pure water automatic recirculation valves save up to 95% of water*.

​

BUILT-IN CUSTOMIZABLE PURIFICATION STEPS:

  • 2.5x10” premium depth PP sediment cartridge filter for 5 micron particles

  • 2.5x10” premium depth PP sediment cartridge filter for 1 micron particles (available only at single pass RO version)

  • 2.5x10” premium thick layer carbon block cartridge filter

  • 4.0x21” high performance reverse osmosis membrane

  • 4.0x21” high performance double pass reverse osmosis membrane (available only at double pass RO version)


OPTIONAL ADDITIONAL FEATURES:

  • Regenerable softener cartridge for high hardness inlet waters.

  • Ultraviolet UV sterilizer.

  • Premium microbiological ultrafiltration cartridge as additional microbiological barrier.

  • Endotoxin filter as additional purification step.



OTHER FEATURES:

  • Permeate outlet pressure can be adjusted by user between 0.2 and 3.5 kgf/cm².

  • 304 stainless steel cabinet structure.

  • 2 doors with keys (front and rear) for easy access for maintenance.

  • Acoustic protection for silent operation.

  • 304 stainless steel valves for rejection, recirculation, pump pressure and pressure relief.

  • 304 stainless steel pressure pump, pressure vessel and pressure gauges.

  • Quick connect PP fittings for easy maintenance.

  • Pressão de saída de água tratada ajutável entre 0.2 e 3.5kgf/cm².

  • Post-carbon sampling valve.

  • Purified water sampling valve.

IMAGE GALLERY
